Oil seals play a crucial role in industrial applications. Beyond preventing lubricant leakage, they also block external contaminants from entering equipment, helping ensure long term reliability. The material used in an oil seal directly affects its performance in high temperature and corrosive environments. Selecting the right material is therefore essential for maintaining equipment stability and extending service life.

NBR Oil Seals: Focused on Oil Resistance

Nitrile rubber oil seals perform well in applications involving oils and petroleum based fluids. They offer strong sealing capability for lubricants, but their heat resistance is limited, typically up to about 125 °C. NBR also has weak resistance to acidic and alkaline substances, making it unsuitable for environments containing strong acids or strong bases.

FKM Oil Seals: High Temperature and Chemical Resistance

For equipment exposed to elevated temperatures, fluorocarbon rubber oil seals are a strong choice. FKM can withstand temperatures up to around 250 °C, and in some cases even higher for short periods. This makes FKM seals common in automotive engines, chemical processing equipment, and other high temperature systems.

FKM also provides excellent resistance to chemical corrosion. It can tolerate strong acids, strong bases, and many organic solvents, which is why it is widely used in environments that demand both heat resistance and chemical stability.

FFKM Oil Seals: Extreme Performance in Harsh Conditions

For the most demanding applications, perfluoroelastomer oil seals offer unmatched performance. FFKM can endure temperatures up to approximately 325 °C or higher, maintaining stability even under extreme heat. It also provides exceptional resistance to nearly all chemicals, including strong acids, strong bases, oxidizing agents, and highly aggressive media. These properties make FFKM seals suitable for aerospace, petrochemical processing, and other critical industries.

EPDM Oil Seals: Reliable in Low Temperature and Water Based Environments

Compared with FKM, EPDM has lower heat resistance, typically ranging from minus 40 °C to about 125 °C. However, it performs very well in corrosive environments involving water based fluids, weak acids, and weak bases. EPDM oil seals are commonly used in automotive systems, air conditioning equipment, and water treatment applications. For low temperature operation or systems using water based media, EPDM is a cost effective option.

PTFE Oil Seals: Exceptional Chemical Stability

Polytetrafluoroethylene oil seals are known for their outstanding chemical stability in extreme environments. PTFE can withstand temperatures up to about 260 °C and is resistant to almost all chemical substances. This makes it suitable for applications such as chemical processing and food production. The main limitation of PTFE is its low elasticity, which reduces its suitability for dynamic sealing. As a result, PTFE is used more often in static sealing conditions.

Choosing the Right Oil Seal Material

Selecting an oil seal material is not simply a matter of choosing the “best” option. The correct choice depends on temperature, speed, media, pressure, and other operating conditions. Understanding the characteristics of each material helps ensure long term stability and reliable performance in specific applications.
